Sunday, June 26, 2016

Convert MIT-BIH Polysomnographic data to mat (Matlab) format

.mat file could be loaded directly into Matlab. But MIT-BIH Polysomnographic data is not a .mat format. although, https://www.physionet.org/cgi-bin/atm/ATM offers a converter that could convert to .mat format, but be careful, it only gives you first 1000000 points, but not all data. So how to convert the whole data file to .mat? Fortunately, the convertion tool "wfdb2mat" is also offered by www.physionet.org. Just go https://www.physionet.org/physiotools/, click "Software Index" https://www.physionet.org/physiotools/software-index.shtml. And find WFDB links
https://www.physionet.org/physiotools/wfdb.shtml, click it. Find "Ready-to-run, precompiled binaries" https://www.physionet.org/physiotools/binaries/. OK, in this page you will find the tool in binary format. I use windows, so I downloaded the windows version.

Here is a command line example:

bin\wfdb2mat -r slpdb/slp14 -f 0 -t 21600  -s 2 >slp14m.info

Make sure you have .hea file along with .dat file. The last command will produce slp14m.mat and other stuffs. slp14m.mat is just you want. Try to load it into matlab:

eegdata = load('slp14m.mat');

All are done!

Tuesday, May 17, 2016

Digital Elliptic Filter in Matlab

(Just learning how to use elliptic filter in Matlab)

The elliptic filter works pretty well, so efficient. The following filter will band 50Hz and near frequencies (see the third figure). And the last figure shows the filtered signal.

==== m code started ====

clear
Rp = 5; % peak-to-peak passband ripple, the smaller the smoother
Rs = 60; % stopband attenuation
Fs = 250; % sample rate
Wp = [47, 53]/Fs*2; % passband edge frequency
Ws = [48, 52]/Fs*2; % stopband edge frequency
[N, Wn] = ellipord(Wp, Ws, Rp, Rs); % find the minimum order of the required filter

fprintf('Wn %f, %f\n', Wn(1)*Fs/2, Wn(2)*Fs/2);

[b,a] = ellip(N,Rp,Rs, Wn,'stop'); % design an elliptic filter
freqz(b,a); % draw frequency response of the filter

title(['ellipord Analog bandstop filter order N=',num2str(N)]);
xlabel('Frequency(Hz)');

tseq = 0: 1/Fs :6;
dataIn =  sin(tseq*10 *2*pi) + sin(tseq*50 *2*pi) + sin(tseq*52 *2*pi) + sin(tseq*48 *2*pi);
dataOut = filter(b,a,dataIn);

figure(2);
plot(dataIn);
figure(3);
plot(dataOut);




Monday, January 18, 2016

vector::operator [] is time consuming

I am handling large amount of data (4000*4000 double). I found vector::operator [] is really expensive in terms of CPU cost.

vector arr = AllocateArray(4000, 4000);
while( _all_elements_in_arr_)
{
  arr[i] = x; // it's extremely slow.
}

So avoid of using operator [], instead, use direct address of the buffer could improve the performance tremendously:

double * buffer_addr = &arr[0];

Friday, December 18, 2015

[IDL 2 CPP] Let Bison/Flex Generate C++ Parser

Although C++ isn't a very modern language, C could make you upset even more. I'm developing a translator which could translate IDL (Interactive Data Language) to C++, and had enough of the ancient C because I need various complex data struct to hold all kind of information that needed when doing the translation. So it's absolutely a good idea that let Bison/Flex to generate a C++ parser. But the way of enabling C++ for Bison/Flex is hard indeed. Bison/Flex lack documents that tells you how to develop a complete C++ parser. When you turn on the C++ option for Bison/Flex, tremendous compiling errors are waiting for you. I read so many articles, and want to say thank you to all these authors. And I will share you the whole cook book of letting Bisong/Flex generating C++ Parser.

Download Win Flex Bison
I tried two windows versions. This is the good one to support C++ parser.
http://sourceforge.net/projects/winflexbison/

Option for Bison
These two options tell Bison to generate a C++ parser. The file lalr1.cc is in the win_flex_bison downloaded package.

%language "c++"
%skeleton "lalr1.cc"

Setup Parser's Class Name
The following option give a name to the parser class.

%define parser_class_name "idl_parser"

The parser class would look like as following

  /// A Bison parser.
  class idl_parser
  {

Pass Essential Arguments to the Parser
You have to pass scanner which would provide yylex, to the parser. The parser could call yylex and obtain a token each time. "translator" could hold some important data, but depends on your needs. "arg_yyin" is the input source code file.

%parse-param {yy::IdlTranslator& translator}
%parse-param {yy::IdlScanner& scanner}
%parse-param {std::ifstream* arg_yyin}
%parse-param {std::ofstream* outputStream}

The parser ctor looks like as following.

idl_parser (yy::IdlTranslator& translator_yyarg, yy::IdlScanner& scanner_yyarg, std::ifstream* arg_yyin_yyarg, std::ofstream* outputStream_yyarg);

All arguments passed in, the parser will store them in member variables.

    /* User arguments.  */
    yy::IdlTranslator& translator;
    yy::IdlScanner& scanner;
    std::ifstream* arg_yyin;
    std::ofstream* outputStream;

Tell the Parser the Prototype of the yylex
"yylval" is used to return token string from scanner to parser. "yylloc" is an argument which could tell the current location in the source file. This parameter is enabled by %locations . If you didn't use %locations, then there would be no yylloc.

The following macro definition usually be defined in scanner header file. And included by bison .y file and flex .l file.

#ifndef YY_DECL
# define YY_DECL                                        \
    yy::idl_parser::token_type                         \
    yy::IdlScanner::lex(yy::idl_parser::semantic_type* yylval, yy::idl_parser::location_type *yylloc)

And in your grammar file (.y) define yylex macro.

#define yylex scanner.lex

The parser will call lex as following

YYCDEBUG << "Reading a token: ";
yychar = yylex (&yylval, &yylloc);

By defining the yylex macro, parser actually calls scanner.lex().

Implementing the Scanner
Pay attention to the first part of the following code please. It redefines yyFlexLexer, so the class yyFlexLexer in file "FlexLexer.h" becomes IdlFlexLexer. It very important, it avoids many conflicts. But it's really a poor technique.

The following is part of the scanner's header file.

#ifndef __FLEX_LEXER_H
#define yyFlexLexer IdlFlexLexer
#include "FlexLexer.h"
#undef yyFlexLexer
#endif

#include "idl.tab.hh"


namespace yy
{
    class IdlScanner : public IdlFlexLexer
    {
    public:
        IdlScanner(std::ifstream* arg_yyin);

        virtual ~IdlScanner();

        virtual idl_parser::token_type lex(
            idl_parser::semantic_type* yylval,
            yy::idl_parser::location_type *yylloc
            );
    };
}

Have a Look at the Implementation of IdlScanner::lex()
The file lex.???.cc is the lexer implementation file. The file is generated by flex. In this file, the macro YY_DECL just defined before, is used here for the implementation code.

YY_DECL
{
register yy_state_type yy_current_state;
register char *yy_cp, *yy_bp;
register int yy_act;
...

How does the Input File Passed into Scanner
The scanner class is derived from class yyFlexLexer which is defined in FlexLexer.h. The input file "std::ifstream* in" is actually passed to the parent class via ctor. Remember yyFlexLexer was defined as IdlFlexLexer.

    IdlScanner::IdlScanner(std::ifstream* in)
        : IdlFlexLexer(in)
    {
    }

The implementation of yyFlexLexer ctor is in file lex.???.cc, which is generated by flex. The input file arg_yyin is stored in yyin, a member variable of yyFlexLexer. yyin is used to be a global variable in C lexer version. If yyin is NULL, then the lexer would use stdin as input.

yyFlexLexer::yyFlexLexer( std::istream* arg_yyin, std::ostream* arg_yyout )
{
yyin = arg_yyin;
yyout = arg_yyout;
yy_c_buf_p = 0;
yy_init = 0;
yy_start = 0;
yy_flex_debug = 0;
yylineno = 1; // this will only get updated if %option yylineno

Invoke the Parser
First create the scanner with the input file, and then pass the scanner to the parser. When you call parser.parse(), the parser will call scanner.lex() to get tokens one by one.

        std::ifstream *inputFile = new std::ifstream();
        inputFile->open("some source file here");

        std::ofstream *outputFile = new std::ofstream();
        outputFile->open("some output file here");

        IdlScanner scanner(inputFile);

        idl_parser parser(*this, scanner, inputFile, outputFile);

        int parse_ret = parser.parse();



Sunday, November 29, 2015

[IDL 2 CPP] Implement Variable Definitions

Since IDL (Interactive Data Language) is a kind of dynamic typed language (dynamic language for short), it doesn't have variable declarations. So we have to add declarations in translated C++ source code.

The basic method of adding declarations is by using mid-rules in Bison grammar file.

As following, initialize a data structure that could store variable names, and then each time the parse meets an assignment statement, store the variable name for future use. The following code show the way of recording variable names. But its not accurate, because unary_expression doesn't equal to variable name, sometimes it's an element of an array or some other ting. So here we need more complex code logic to accomplish it. But I won't put these code here because here is just a show of high level of structure of the method.

assignment_statement:
unary_expression '=' expression
{printf("bison got assign statement: %s = %s\n", $1, $3);
VariableNameSet_TryAdd($1);
$$ = AllocBuff();
sprintf_s($$, TEXT_BUFFER_LEN, "%s = %s;", $1, $3);
}
;

And at last, when composing the C++ function, put the variable declarations at the beginning of the function.

function_definition:
KEY_FUNCTION identifier parameter_list_line
{
VariableNameSet_Init();
}
statement_list KEY_END end_of_line
{
char *buf = AllocBuff();
IncreaseTab($5, buf);

$$ = AllocBuff();

char *var_decl_buf = AllocBuff();
VariableNameSet_DecleareVariables(var_decl_buf);

char *var_decl_buf_tabbed = AllocBuff();
IncreaseTab(var_decl_buf, var_decl_buf_tabbed);

sprintf_s($$, TEXT_BUFFER_LEN, "Variant %s%s{\n%s%s}%s\n", $2, $3, var_decl_buf_tabbed, buf, $7);
printf("IDL function: [%s]\n", $$);
}
;




Saturday, November 28, 2015

[IDL 2 CPP] Translate IDL Array Subscript Ranges to C++

I started a project that translates huge amount of IDL codes to C++ for sake of performance improvements. IDL is acronym for Interactive Data Language. This is IDL's homepage. And here is Wikipedia page.

Since the original data processing program which was written in IDL is so large, it's impossible to translate manually, I decide to develop a translator then translate it into C++ source code. I've worked on it for a couple of weeks. And today I finished the ranged array part. I think it's interesting so I'm going to share the development experience for you.

I am using flex/bison to generate a parser. The grammar rules for IDL's array and subscripts are here(ask me for sample code):

postfix_expression:
primary_expression
| postfix_expression '[' array_subscripts ']'

array_subscripts:
array_subscript
| array_subscripts ',' array_subscript
;

array_subscript:
expression
| range_or_whole_range ':' range_or_whole_range
;

range_or_whole_range:
expression
| '*'
;

No action codes here yet. These grammar rules cover simple array subscripts which will visit an element of an array, and also the subscript ranges case. For the simple case, the IDL code is easy to translate. For example, IDL code:

a = b[1]

which would be translated to

a = b[1];

Just exactly the same code in C++. But it would be more complex if the code uses ranged array, like this:

a = b[1:10]

Since there is no relevant grammar in C++, we have to do some fundamental support in C++. Firstly, there should be an object which could represent a range of an array. Say, we have this:

class ArrayDimDesc
{
int size;
int startIndex;
int endIndex;
};

class RangedArray
{
void* array;
int Dimensions;
ArrayDimDesc arrayDimDesc[8];
};

So IDL ranged array b[1:10] could be represented by class RangedArray object. This way made things easier. Replace b[1:10] by a function call to MakeArrayRange1D(), the whole statement can be translated just as simple array subscript case.

Let me show you a more complex IDL code:

coeffbk = where(sset.bkmask[nord:*, 1, 2:3] NE 0)

And the translated C++ code is:

coeffbk = where(MakeArrayRange3D(sset.bkmask, nord, -2, 1, -1, 2, 3) != 0);

I haven't finished all the work. But the main idea is just as above. There are lots of further work to do:
1, Memory management
2, Introduce smart pointer?
3, Is it necessary to move MakeArrayRange3D in front of the statement?



==== BISON grammar rules for IDL ranged array ======================
postfix_expression:
primary_expression
| postfix_expression '[' array_subscripts ']'
{
$$ = AllocBuff();

// check if array_subscripts is a range
if(IsRangedSubscripts($3))
{
FillMinusOneToEmptyRange($3);
// case 1: range, compose a ranged array; $3 is subscripts
// MakeArrayRange(array, startIndex, endIndex)
if($3->dimension == 1)
{
// 1 dim
sprintf_s($$, TEXT_BUFFER_LEN, "MakeArrayRange1D(%s, %s, %s)",
$1,
$3->subscriptsRange[0].rangeStart,
$3->subscriptsRange[0].rangeEnd);
}
else if($3->dimension == 2)
{
sprintf_s($$, TEXT_BUFFER_LEN, "MakeArrayRange2D(%s, %s, %s, %s, %s)",
$1,
$3->subscriptsRange[0].rangeStart,
$3->subscriptsRange[0].rangeEnd,
$3->subscriptsRange[1].rangeStart,
$3->subscriptsRange[1].rangeEnd);
}
else if($3->dimension == 3)
{
sprintf_s($$, TEXT_BUFFER_LEN, "MakeArrayRange3D(%s, %s, %s, %s, %s, %s, %s)",
$1,
$3->subscriptsRange[0].rangeStart,
$3->subscriptsRange[0].rangeEnd,
$3->subscriptsRange[1].rangeStart,
$3->subscriptsRange[1].rangeEnd,
$3->subscriptsRange[2].rangeStart,
$3->subscriptsRange[2].rangeEnd);
}
else
{
// unsupport dimension
yyerror("Unsupported array dimension in ranged array, dimension is %d.\n", $3->dimension);
YYABORT;
}
}
else
{
// case 2: scalar, simple and easy case
char *subscript_buf = AllocBuff();
subscript_buf[0] = 0;
int pos = 0;
for(int i=0; i<$3->dimension; i++)
{
sprintf_s((subscript_buf+pos), TEXT_BUFFER_LEN, "[%s]", $3->subscriptsRange[i].rangeStart);
pos = strlen(subscript_buf);
}

// ##ATTENTION :IDL array subscripts are different than those of C++'s##
sprintf_s($$, TEXT_BUFFER_LEN, "%s%s",
$1,
subscript_buf);

// release subscript_buf
}

printf("array final code: %s\n", $$);
}
| postfix_expression '.' IDENTIFIER
{
$$ = AllocBuff();
sprintf_s($$, TEXT_BUFFER_LEN, "%s.%s", $1, $3);
}
| function_call
;

array_subscripts:
array_subscript
{
$$ = Malloc(sizeof(struct ArraySubscripts));
$$->dimension = 1;
strcpy($$->subscriptsRange[0].rangeStart, $1->rangeStart);
strcpy($$->subscriptsRange[0].rangeEnd, $1->rangeEnd);

// release $1
}
| array_subscripts ',' array_subscript
{
strcpy($$->subscriptsRange[$$->dimension].rangeStart, $3->rangeStart);
strcpy($$->subscriptsRange[$$->dimension].rangeEnd, $3->rangeEnd);
$$->dimension++;
}
;

array_subscript:
expression
{// single subscript
struct ArraySubscript *pArraySubscript = Malloc(sizeof(struct ArraySubscript));
strcpy(pArraySubscript->rangeStart, $1);
pArraySubscript->rangeEnd[0] = NULL;
$$ = pArraySubscript;
}
| range_or_whole_range ':' range_or_whole_range
{// Ranged subscript
struct ArraySubscript *pArraySubscript = Malloc(sizeof(struct ArraySubscript));
strcpy(pArraySubscript->rangeStart, $1);
strcpy(pArraySubscript->rangeEnd, $3);
$$ = pArraySubscript;
}
;

range_or_whole_range:
expression
| '*' { $$ = "*"; }
;

Wednesday, March 11, 2015

Optimizing by ANSYS - Objective Function Defined by Other Software

Key Points:

  1. You have an objective function to be optimized (to find a minimum/maximum point)
  2. But the function is defined by a software other than ANSYS
  3. The function doesn't have a mathematical formula


Suppose you have an objective function which is defined by a complex software, say an FEM or CFD software. The function has one or several variables, and the function generates different values regarding different variable values input.

Basic idea of the solution is by using /sys command in ANSYS APDL code which let ANSYS to invoke your software, and evaluate the function. ANSYS will invoke your software repeatedly until it finds a minimum/maximum point.

Key points for data transfering from ANSYS to your software and vice versa:
1, Your software that defining the objective function should parameterizing the model (the function), so that it can accept one or more parameters and generates the function value.
2, Your software should have a way of passing value to parameter(s), such as command line or an input file.
3, Your software should have a way of passing back the function value, such as program exit code or an output file.

Here is an example of the solution with the way of passing value that passes data by input/output file.

TASCA is the software which defines the objective function. "tascain.txt" is the input file, and tascout.txt is the output file.

vwrite puts the value of X to the input file. Then the code invokes TASCA. TASCA will read the data from "tascain.txt", and evaluate the function, and then writes the function value to "tascaout.txt". The function value will be read from the file and stores in A1 and V.

FILE: volu.inp
*DIM, A1, array, 2,1

X=1.4

*cfopen, tascain,txt
*vwrite, X
(F10.2)
*cfclose

/sys, TASCA evaluate

*vread, A1(1,1), tascaout,txt, c:\working, JIK, 1,1
(F6.2)

V=A1(1,1)


The following shows the optimization control file. V defined as the objective function. The makes ANSYS to find the minimum value of the objective function. To start optimization, type these command in the command input box of the ANSYS: /input, optovlu,inp .

FILE: optvolu.inp
/clear,nostart
/input,volu,inp
/opt
opanl,volu,inp
opvar,X,dv,1.3,1.9,1e-2
opvar,V,obj,,,1e-2
opkeep,on
optype,subp
opsave,optvolu,opt0
opexec
